Description
Description
The BASS 3K has been carefully designed with the highest technology, with high efficiency and performance for car audio systems aimed at sub-bass and bass responses, in the frequency range of 8Hz to 250Hz. It has a maximum power of 3000 Watts in 1 channel of 1 ohm, It features customized adjustments according to the trunk size and the most prominent frequency of each vehicle, through BASS BOOST and the option to choose the central frequency. This amplifier offers much more displacement control, through its SUBSONIC FILTER, volume control and LOW PASS, to get your bass just perfect. Welcome to the audio world by Taramps!
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 14.4 VDC - 1 Ohm: 3000 Watts RMS @ 14.4 VDC - 2 Ohms: 1920 Watts RMS |
| Input Sensitivity | 220mV |
| Signal to Noise Ratio | > 95dB |
| Frequency Response | 8Hz ~ 250Hz (-3dB) |
| Crossover high pass (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| Crossover low pass (LPF) | 60Hz ~ 250Hz (-12dB/8ª) Variable |
| bass boost | Freq.: 35Hz ~ 60Hz / Boost: 0 ~ +10dB |
| Efficiency | 80% |
| Input Impedance | 15K Ohms |
| Output Impedance | 1 Ohm |
| protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| Min. Supply Voltage | 9 VDC |
| Maximum Power Supply Voltage | 17 VDC |
| Consumption at rest | 1.10A |
| Maximum music consumption | 130A |
| Maximum consumption in sinusoidal signal | 260A |
| Dimensions (WxHxD) | 9.41" x 2.87" x 8.58" (239 x 73 x 218mm) |
| Weight | 6.51lb (2.96Kg) |
| EAN | 7898556844789 |
