Description
Description
The DS 2000×4 is a Taramps multi-channel amplifier, carefully designed with the latest technology. It features 4 channels of 500 Watts RMS each, with maximum power of 2000 Watts RMS altogether, at 2 ohms and is suitable for any frequency, that is to say, it is FULL RANGE. Versatility, efficiency and quality in a single Taramps product.
Technical Information:
| Operation class | D |
|---|---|
| Number of Channels | 04 |
| Maximum power | @ 14.4 VDC - 2 Ohms: 2000W RMS (4 x 500W RMS) @ 14.4 VDC - 4 Ohms: 1300W RMS (4 x 325W RMS) 2 Bridged Channels (2 x 1000WRMS) at 4 Ohms |
| Input Sensitivity | 250mV |
| Signal to Noise Ratio | >86dB |
| Frequency Response | 8Hz~20KHz (-3dB) |
| Crossover high pass (HPF) | 90Hz (-12dB/8a) Fixed |
| Crossover low pass (LPF) | 90Hz (-12dB/8a) Fixed |
| Input Impedance | 18K Ohms |
| protection system | Output Overload |
| Min. Supply Voltage | 9VDC |
| Maximum Power Supply Voltage | 17VDC |
| Consumption at rest | 2.2A |
| Maximum music consumption | 100A |
| Maximum consumption in sinusoidal signal | 200A |
| Dimensions (WxHxD) | 10,55" x 2,83" x 9,64" (268 x 72 x 245mm) |
| Weight | 7,42lbs (3,37Kg) |
| EAN | 7898556847902 |
