Description
Description
The DS 250×2 is designed with a size that fits in your hand. This amplifier was made for those who like to hear the full range of frequencies, bass, mid and high as well, and for that reason, it suits all types of customers and car audio systems. It is stereo, has 2 channels of 125 Watts RMS at 2 ohms or 1 bridged channel with 250 Watts RMS at 4 ohms. The perfect car audio style for you!
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 02 |
| Maximum power | @ 12.6 VDC - 2 Ohms: 250 Watts RMS (2 x 125W RMS) @ 12.6 VDC - 4 Ohms: 158 Watts RMS (2 x 79W RMS) 1 bridgeable channel - @12.6 VDC - 4 Ohms: 250W RMS (1 x 250W RMS) |
| Input Sensitivity | 250mV a 6V |
| Signal to Noise Ratio | >88dB |
| Frequency Response | 8Hz ~ 35KHz (-3dB) |
| Crossover high pass (HPF) | 80Hz ~ 2.2KHz (-6dB/8th) Variable |
| Crossover low pass (LPF) | 80Hz (-12dB/8th) Fixed |
| Input Impedance | 10K Ohms |
| Output Impedance | 2 Ohms |
| protection system | Output short circuit |
| Min. Supply Voltage | 9 VDC |
| Maximum Power Supply Voltage | 16 VDC |
| Consumption at rest | 0.63A |
| Maximum music consumption | @12.6 VDC: 15A |
| Maximum consumption in sinusoidal signal | 30A |
| Dimensions (WxHxD) | 138 x 49 x 121mm |
| Weight | 0,46kg |
| EAN | 7898556844567 |
