Power, efficiency and high performance are some of the synonyms of this module. It can reach a maximum power of up to 160,000 Watts. It features thermal protection and anti short circuit. It is powered by batteries in series, as it uses batteries as its source of energy. It is a unique line in its category, delivering extremely high power for mid and large car audio systems. Standing Out for its efficiency from sub-bass to mid-high, with high performance in timbres and audio quality.
Technical Information:
| Number of Channels | 01 |
|---|---|
| Output Voltage | 300VDC @ 0.5 Ohm - 24 Batteries |
| Maximum Power @ 300VDC- 0,25 Ohm | 160.000W (For competition) |
| Input Sensitivity | 360mV ( Level 100%) @ 0.5 Ohm |
| Aux Input standard | 0.2% |
| Signal to Noise Ratio | >95dB |
| Frequency response | 10Hz ~ 15KHz (-0.5dB) |
| Efficiency | 90% @ 0.5 Ohm (full Power) |
| Input impedance | 27K Ohms |
| Protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| Power Supply Voltage | 180VDC |
| Power Supply Voltage | 360VDC |
| Consumption at rest | 125mA to 300VDC |
| Maximum Musical Consumption @0,25 Ohm | 280A |
| Maximum Sinusoidal Consumption @0,25 Ohm (100Hz) | 560A |
| Dimensions (H x W x D) | 9.41" x 2.87" x 22.07" (239 x 73 x 561mm) |
| Weight | 16.28lb (7.40Kg) |
| EAN | 7898556844062 |
