Description
Description
The Taramps MD 5000.1 in the 2-ohms version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the whole frequency range, that is to say that it is a FULL RANGE (10Hz ~10 KHz (-3dB) module. It is classified as mono and has a channel with a maximum power of 5000-Watts RMS. Welcome to Taramps audio world.
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 12.6 VDC - 2 OHMS: 5000W RMS @ 12.6 VDC - 4 OHMS: 3200W RMS |
| Input Sensitivity | 220 mV |
| Signal to Noise Ratio | >90dB |
| Frequency Response | 10Hz ~ 10KHz (-3dB) |
| Crossover high pass (HPF) | 10Hz ~ 90Hz (-12dB/8ª) Variable |
| Crossover low pass (LPF) | 90Hz ~ 10KHz (-12dB/8ª) Variable |
| bass boost | 0 ~ 10dB (50Hz) Variable Frequency (35 ~ 55) |
| Efficiency | 86% |
| Input Impedance | 15K Ohms |
| Output Impedance | 02 OHMS |
| protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, low/high supply voltage and Thermal protection. |
| Min. Supply Voltage | 9VDC |
| Maximum Power Supply Voltage | 16VDC |
| Consumption at rest | 1.40 A |
| Maximum music consumption | 230.5 A |
| Maximum consumption in sinusoidal signal | 461 A |
| Dimensions (WxHxD) | 8.98" x 2.76" x 12.87" (228 x 70 x 327mm ) |
| Weight | 9.28lb (422kg) |
| EAN | 7898556844499 |
