Description
Description
The Smart 3 BASS is another innovation by Taramps. Aiming at car audio systems. The exclusive Power Control System technology, now specific for subwoofers, ensures even more quality at low frequencies delivering more security by monitoring the whole amplifier operation. It is multi-impedance, single channel amplifier, that is, it delivers the 3000 WRMS in any impedance between 0.5 and 2 ohms. It has an indicative logo that you already know, robust power input, connecting cables up to 1 AWG (50mm²) as well as an output for CLIP monitor. Dive into this new experience with Taramps Group!
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 14.4 VDC - 0.5 Ohm: 3000 Watts RMS @ 14.4 VDC - 1 Ohm: 3000 Watts RMS @ 14.4 VDC - 2 Ohms: 3000 Watts RMS @ 14.4 VDC - 4 Ohms: 1700 Watts RMS |
| Input Sensitivity | 4V ~ 0.2V |
| Signal to Noise Ratio | >90dB |
| Frequency Response | 8Hz ~ 200Hz (-3dB) |
| Crossover high pass (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| Crossover low pass (LPF) | 60Hz ~ 200Hz (-12dB/8ª) Variable |
| bass boost | Freq.: 35Hz ~ 60Hz Boost: 0 ~ +10dB |
| Efficiency | 75% |
| Input Impedance | 10K ohms |
| Output Impedance | 0.5 ~2 ohms |
| protection system | Output short-circuit low/high supply voltage thermal protection |
| Min. Supply Voltage | 9 VDC |
| Maximum Power Supply Voltage | 17 VDC |
| Consumption at rest | 1.10A |
| Maximum music consumption | 190A |
| Maximum consumption in sinusoidal signal | 278A |
| Dimensions (WxHxD) | 9.37" x 2.80" x 9.45" (238 x 71 x 240mm) |
| Weight | 6.60lb (3Kg) |
| EAN | 7898556847414 |
